Retevis RB17P is a simple-to-operate GMRS handheld radio for outdoor use.
It has a unique split-screen design and a dedicated sub-screen to display NOAA information;
one-key alarm function and half-keyboard design make it an ideal communication tool for outdoor communication.
GMRS repeater capable.
FREE shipping
Retevis RB17P Easy Use GMRS handheld Radio
Half keyboard design, support full function key change, NOAA weather alert function, one key alarm function for emergency situations, Retevis RB17P is ideal for the family farm, outdoor activities communication.
Retevis RB17P GMRS Handheld Radio Features
- Two Year Warranty
- Full 5Watt GMRS handheld Radio
- 128 GMRS Channels, channel name display
- 8 default GMRS repeater capable channels
- 282 Privacy Codes(50 CTCSS+83 CDCSS) - Bring you safe calls without interruptions.
- One key Alarm Function(local or local+ remote)-In case of emergency, one-click alarm can let you be found in time.
-
half keypad design, simple use GMRS handheld radio
-
LCD display, Split display, sub-screen showing NOAA
- CH mode-frequency; channel NO.channel name mode.
- Channel mode can be edited by keypad.
- Power selection-high 5W, Low 0.5W
- Power saving mode
- backlight time selection-5s;10s;30s;Always
- 8 optional background colors fit for various scenarios-Black; Red; Green; Yellow; Blue; Purple; Cran; White.
- One side key definable-NOAA; Monitor; Scan;VOX; 2nd PTT; off.
- VOX-0-9 can be selected by keypad; VOX delay
- bandwidth adjustable-wide and narrow band available-can change by keypad
- SQL-Squelch level 0~9 can be selected by keypad
- dual-band standby, dual display.
- Power saving mode
- Compand; Scramble.
- Keyboard lock; busy lock by keypad.
- Monitor, Scan,
- Beep
- Roger
- Scan mode can be selected by keypad-CO; TO; SE.
- TOT
- Reset by keypad.
- Factory reset menu contains the cancellation of all preset privacy codes
- USB Charging Base and Type-C USB charging Cable.
- GMRS License Required
- FCC ID: 2ASNSRB17P
- Dimensions- 4.72 x 2.28 x 1.53 inches
Package Includes
- 1X Retevis RB17P GMRS handheld radio
- 1X 2200mAh rechargeable Li-ion battery
- 1X Belt Clip
- 1X Hand Strap
- 1X USB Desktop Charger
- 1X Charger adapter
- 1X User’s Manual
Technical parameters:
| General Specifications | |
| Frequency Range | GMRS: TX: 462.5500-467.7125MHz RX:462.5500-467.7250MHz |
| Channel Capacity | 128 |
| Channel Spacing | 12.5KHz |
| Antenna Impedence | 50Ω |
| Frequency tolerance | ≤2.5×10-6 |
| Working Voltage | 7.4V DC |
| Battery capacity | 2200mAh（Li-ion） |
| Size | 120（H）*58（W）*39（D）mm |
| Operating temperature | -30~+60°C |
| net weight | About 250g |
| Transmitter | |
| Output Power | 5W/0.5W |
| Carrier Frequency Tolerance | ≤2.5×10-6 |
| Modulation Mode | 11K0F3E |
| Modulation Limiting | ±2.5K |
| Modulation Distortion | ≤5% |
| Audio Response | +1/-3 dB |
| FM Hum & Noise | <-35 dB |
| Transmit spurious emission | ≤-36dBm@9kHz～1GHz≤-30dBm@1GHz～12.75GHz |
| Adjacent Channel Power | >60dB |
| Receiver | |
| Squelch Sensitivity | ≤0.22 μV |
| Audio Power | 1W@16Ω |
| Audio Distortion | <5% |
| FM Hum & Noise | <-38dB |
| Inter-modulation response immunity | ≥65dB |
| Adjacent channel selectivity | ≥60dB |
| Co-Channel inhibition | ≥-12dB |
| Spurious Response Immunity | ≥70dB |
| Blocking | ≥85dB |
Retevis RB17P Brochures
Retevis RB17P Software
Retevis RB17P Update Setup
Retevis RB17P Manual
Please fill in your procurement needs and contact information
Clear, large battery capacity
At Elk Camp we are often in areas without cell service and these radios allow us to communicate with each other. These are reliable, with clear sound and decent range. The battery lasts a long time on a single charge and can be charged via a power bank with a USB port. Love them very much!
The sound quality is great
The sound quality is great. The battery lasts approximately 15 hours. Almost any 2-pin microphone and headset will work with them. The NOAA-dedicated button on the side was a surprise, and there was an alarm/SOS button on the top as well.
These are great for hiking, camping, quad biking, and even multi-vehicle road trips through areas with poor signal coverage.
The programming software is fairly simple and should be easy for most people to use.
